1.Not using color marker tracking.

2.Weak color marker on the film.

3.Film slipping.

1.In the tracking method display on the HMI (Human-Machine Interface), change the tracking method to "Cutting Tracking."

2.Refer to the accompanying Magic Eye instruction manual to adjust the sensitivity of the Magic Eye.

3.Refer to the accompanying Magic Eye instruction manual to adjust the sensitivity of the Magic Eye.

1. 1.Push rod and cutter are asynchronous.
2. 2.Improper height of the cutter seat.
3. 3.Packing speed is too high.

1. 1.Refer to section 4.6.4 for the push finger position.
2. 2.Adjust the height of the end sealing component to align the engagement center of the sealing cutter with half the height of the product.
3. 3.Reduce the packaging speed.

1. 1.Temperature is too high.
2. 2.Speed is too low.
3. 3.Poor heat resistance of the outer layer of the film.

1. 1.Lower the temperature.
2. 2.Increase the speed.
3. 3.Replace with a better film.

1. 1.Temperature is too low.
2. 2.Speed is too high.
3. 3.Poor heat resistance of the inner layer of the film.

1. 1.Increase the temperature.
2. 2.Decrease the speed.
3. 3.Replace with a better film.

1. 1.Heating element is damaged.
2. 2.Solid-state relay is burned out.
3. 3.Thermocouple is damaged.
4. 4.Temperature controller is damaged.

1. 1.Replace the heating element.
2. 2.Replace the solid-state relay.
3. 3.Replace the thermocouple.
4. 4.Replace the temperature controller.
